Ingenico AXIUM RX7000 - 4_4 Setting the RX7000 on the Standpole Adaptor

Ethernet connector
 USB cable (optional)
Reference : 296107316AD(length 1.5m)
Connector for terminal Power supply unit
USB host & device connector
Remarks: Rated output of USB:5Vdc 0.5A （Normal condition）
Rated output of USB:5Vdc 2.5A （Single fault condition）
4_4 Setting the RX7000 on the standpole adaptor
Install the terminal on a flat surface is not possible on the RX7000 as is. It is designed to
be fitted on a standpole adaptor.
A specific pattern by Ingenico has been developed to fit the RX7000.
