Technical Manual ICT220 • 4/36
Copyright © 2009 Ingenico All rights reserved
1. Equipment
The ICT220 is the first terminal of the new Ingenico ready to stay in the market for long.
It puts together power of new processor, latest security, fast printer, large memory and best
design for keyboard with its large keys, display and its general casing.
It is a countertop, with wires for power supply or to communicate (Ethernet or Modem). But
this terminal is suitable for both the merchant and customer as it can be handling very easily,
especially equipped with its Magic Box.
ICT220 is:
• powerful,
• highly secure,
• very robust,
• very reliable,
• easy to operate.
1.1. General hardware description
1.1.1. Main characteristics of ICT220 Countertop terminal
Main processor
− RISC ARM9 32 bits running at 450 Mips
Crypto processor
− RISC ARM7 32 bits running at 50Mips
Internal memory
− SDRAM : 8 Mb
− FLASH : 16 Mb
Display
− White Backlit 128 x 64 pixel graphic display
Keypad
− 15 keys (including 3 colour keys "Validation", "Correction"
and "Cancel")
− 4 navigation keys
− White backlit
Buzzer
− yes
Main Smart card reader
− synchronous and asynchronous
Clock frequency 4.76 MHz
− Vcc = 5V, 3V, 1,8V
Magnetic card reader
− Track 1/2/3
2 SAMs
− 2 in standard
− asynchronous
− Clock frequency 4.76 MHz
− Vcc = 5V, 3V, 1,8V
Communications
− Modem : V22, V22bis, v29 fast connect, V32, V32bis
− Auto answer
− Fast connect
Connections on terminal
− 1 USB slave
− 1 USB master
− 1 RS232
− 1 telephone line in
Printer
− Thermal printer with graphic mode
− Paper detection
− Easy loading
− 42 characters per line
