Ingenico iWL2 Series - Installing Paper Roll

4.4.2. Installingpaperroll

• OpenthepapercompartmentbyliftingthecatchlocatedattherearoftheiWL2XXand
pullthecovertotherearoftheterminal.










• Insertthe paper roll in thecompartmentfollowingthe directions shown onthebelow
picture

• Pullthepaperuptothetopoftheterminal

• Maintainthepaperandclosethecover

• Presssimultaneouslyonbothuppercornersofthepaperflap,asshownbyredarrows
onpicture,untilitclipsintoposition













ADVICE

If you insert a new R40 paper roll, tear off the first length (one complete turn to avoid
printing on adhesive tape footprint). This is not necessary on R25 paper roll as it has no
tape.

