4.5. Battery
4.5.1. Maincharacteristics

Li‐ion
Characteristics
Capacity 2050mAh
Charge
50%capacityin1.5h;fullcapacity
in4hours
Autonomy*
500typicaltransactions
upto250hinstandby

*dependontheterminaltypeanditsbase.

4.5.2. Installingthebattery
WARNING

Switchofftheterminalpriortoconnectingthebattery.
• Turn your terminaland unclip the battery trapdoorby
pushing on the clips with your nails as shown on the
picture

• Disengagethetrapdoor













• Takethebatterypackincludedinthebox

• Locatethebatterypackconnectorbesidethebattery
compartment


• Plugthebatterypackconnectoraccordingtothe
connectorlocatingsystemandtheredwire(as
shownonpicture).
Verifythatitlocks.

• Placethebatterypackinitscompartment.

• Checkthatthewires’pathisflat

• Closethebatterycompartmenttrapdoor.
Redwire

Batterycompartment


iWL2xxWirelessSeries• 15/28
