4leds

(B&Wdisplayonly)

Active

zone



Contactless(optional)



• Bringthecardfirmlyuptotheactivezone.Keepthe

cardclosetothereaderduringthetransaction



• The4LEDsindicatetransactionprocessing(asshown

onthepicture).OncolorscreenterminalvirtualLEDs

aredisplayed.



Theterminalbehaviorforthecardholdermaydependon:

• Theterminalenvironment

• Localusage(language…)



3.4. Installingtheterminalonthebase

Connectingtheterminalonthebase



PlacetheiWL2XXbetweentheflangesonitsbasesothatthecontactsoftheiWL2XX

engageonthecontactsprovidedonthebase(seepicturebelow).



Usingthemodembase(ifmodemfittedonyourbase)

Onceinstalled,thebasemodemisdesignedtoalwaysbepluggedintothemainsnetwork

andbeconnectedtoatelephoneline.Thetelephonelineshouldnotbeshared.



Theportablemaybeplacedbackonitsbaseaftereachtransaction.Itmustbeplacedonits

modem base when telephone network is used for : authorization request, remote

collection,downloading.



iWL2xxWirelessSeries• 9/28

900003061R1100004/1050Allrightsreserved

Ingenico iWL2 Series User Manual
