iWL2xxWirelessSeries• 18/28

900003061R1100004/1050Allrightsreserved



5. Base

IXL2xxBaseisavailableindifferentmodels.Pleaseselectbyyourselfinthisdocumentation

itemsrelatedtoyourmodel.



WARNING



Turn off base power supply unit before connection operation.



5.1.1. Baserearconnections



WARNING

A

B

C

E

D

F

Selectanelectricalsocketthatcomplieswiththegeneralsafetyinstructiongiveninsection

6“Recommendations”ofthisdocument.

Followthebelowinstructions:

• Connectthepowersupplyunitafterallotherconnections.

• ConnectthepowersupplyunittothebasesocketB.

• Connectthepowersupplyunittothemainsnetwork.



A=Ethernetsocket(optional) B=powersupplyunitsocket

C=Pathforwires. D=USBSlavesocket‐CDCserialmodeonly(optional)

E=USBhostSocket1(optional) F=USBhostSocket2(optional)


