4.5.3. Chargingthebattery

¾ Whendoesthebatteryneedtobecharged?
• Oninitialstartup
,chargethebatteryfor16hoursundertheenvironmental
conditionsstatedabove
• Whenuseddaily,
theterminalrechargesitsbatterieseachtimeitisplacedonits
baseoreachtimethetravellerchargerisconnected.Chargingisautomatic

¾ Howdoesthebatteryneedtobecharged?

• Theenvironmentinwhichthechargetakesplaceinfluencesbatterylifetimeand
autonomy(numberoftransactions)

Theoptimalconditionsareasfollows:
 Chargingawayfromanyexternalheatsource(radiator,sun,enclosedarea…)
 Theoptimaltemperatureisbetween+15°Cand+25°C

¾ Howcanthebatterybecharged?

Usingthebase
• Placetheterminalonitsbase

• Checkifthebatterysymbolisflashingormoving(=batterycharging).

Usingthepowertraveladapter(theterminalisoutofitsbase)


• ConnectthetravellerpowersupplyunittotheterminalmicroABconnectorlocated
ontheleftsideoftheterminal.

• Connectthepowersupplyunittothepowersupplymainsnetwork

• Checkifthebatterysymbolisflashingormoving(=batterycharging)
