4.5.4. Changingthebattery
ItisimperativetouseabatteryauthorizedbyIngenico.

ThereisdangerofexplosionifbatteryusedisnotapprovedbyIngenico.

• Removetheterminalfromitsbase
• Turnitoffbypressingsimultaneously
and (yellowkey)for
aboutonesecond
• Removethebatterytrapdoor(seesection4.5.2“installingbattery”)

• Liftthebatteryandremoveitfromitscompartment

• Carefullydisconnectbattery,followingthe
instructionsbelow.

a)Unlocktheconnectorbypressingthelocking
mechanismasindicatedbyF1arrowwhilepulling
wires(F2arrow),todisconnecttheconnector.
Releasetractiononitassoonastheconnector
comesunclipped
 b)Finishextractingconnectorbytiltingitslightly
(F3arrow)tobringitawayfromtheterminal
housing
• Connectandinstallthenewbatterybyfollowingtheinstructionsinsection4.5.2
“Installingbattery”
• Closethebatterytrapdoorandchargethenewbattery.Seesection"0“Charging
theBattery"
• Inordertopreservetheenvironnement,disposeusedbatteryincompliancewith
currentcountryrecyclinglegislation.
• Iftheterminalisstoredforalongtimeremovethebatteryfromtheterminal.

