User’s Manual
To
This field allows the user to input value of time (yyyy-mm-dd) or pick out a specific date
from calendar.
Sensor Type
This field allows user to set Sensor Type to filter which sensor type display at the table.
The options are “All types”, “Zigbee-HT”, “RS485-HT”, “Zigbee-I/O” and “RS-485 I/O”.
Severity
This field allows user to set which severity level for log display. The options are
“Information”, “Warning” and “Critical”.
[Critical]: Critical level event display only.
[Warning]: Warning and Critical level event display
[Information]: Information and Warning and Critical level event will be display
Show entries per page
This field allows user to set how many entries per page. It has four options that includes
10, 20, 50 and 100. Once logs have over a page, the reaming logs will display at next
page.
Export
Clicking this field will save log to local in csv format. For example, From 2014-02-14; To:
2014-02-28, only save logs during this period in the saved file.
Export All
Clicking this field will save log to local in csv format. For example, whatever the period
will save all logs in the local.
Event Log Table
There are five columns below in the Event Log table. Except Event column, each
columns can be sorted by or .
Date & Time
The Date & Time when the system event occurred.
Sensor Type
This field shows the specific sensor type.
Sensor Name
This field shows the sensor name.
Description
The description of the event which occurred at the recorded time.
