INIM Electronics SmartLoop Programming Manual

Programming Manual
The SmartLoop control panel 11
3.2 The buttons
3.3 The LED
Table 1: The status LEDs
TEST
Initialises the test phase and activates all the control panel LEDs.
BUZZER
Silences the control panel buzzer. The buzzer will be unsilenced automatically if
another event occurs. RESET operations also silence the buzzer.
INVESTIGATE
If this button is pressed during Pre-alarm status, it will activate a pre-set alarm delay.
SILENCE
If this button is pressed once, it will silence the NAC outputs, fault output and all
'Silenceable' outputs. If this button is pressed again, it will toggle (undo) the silence
command.
RESET
Resets the control panel (clears alarms).
EVACUATE
Activates the "Evacuate" phase. If this button is pressed by a building occupant
during pre-alarm status (Level 1- no access code or key required), it will generate an
instant alarm.
If this button is pressed after valide key or code entry (Level 2), it will generate an
instant alarm regardless of the system status.
STATUS Group
DESCRIPTION COLOUR MEANING
ALARM Red The control panel is in alarm status. This LED goes On to signal the following
conditions:
- Alarm status of a point defined as an "Alarm" point
- "Evacuate" phase running (triggered by the EVACUATE button on the control
panel or a connected Repeater panel)
- "Evacuate" phase running (triggered by the EVACUATE button on a Network
control panel or Network Repeater panel)
PRE-ALARM Red The control panel is in pre-alarm status. This LED goes On to signal the alarm
status of a point programmed as an "Alarm" point with the "Pre-alarm"
attribute.
DISABLED Yellow If this LED is On, at least one of the system objects (point, zone, output,
communicator, etc.) has been disabled.
TEST Yellow If this LED is On, at least one of the system objects (point, zone, output,
communicator, etc.) is in test status. A zone test affects all the points of the
zone concerned.
NIGHT Yellow If this LED is On, the control panel is operating in Night mode. During Day
mode, the control panel can generate pre-alarms and hold silence status for an
unlimited time. During Night mode, the control panel can hold silence status for
the pre-set time only. During Night mode, the control panel cannot generate
pre-alarms as this function is disabled.
In Service Green If this LED is On, the control panel is powered and working.
