Programming Manual
14 How to use the display and keypad
Chapter 4
How to use the display and keypad
All SmartLoop models, except for the SmartLoop2080/S and SmartLoop1010/S, allow users to
operate the system from the control panel keypad. All control panels allow users to operate the
system from connected SmartLetUSee/LCD Repeater panels.
Most of the conventions relating to the operating principles of following menu screens (navigating
method, space, changes, etc.), are common to all menu screens.
Attention: The procedures described in this section will not be repeated in other parts of this
manual, however, any exceptions to this procedure will be described.
4.1 Selecting an option
This section describes how to navigate through the menus and which options to select:
FROM PANEL
<any key>, 8 Programming, <code>, 1 Configuration, 2 Modify
Configuration, 1 AUTO Configuration , 2 Loop,
or
<any key>
,
8 <code> 1
2 1 2
4.1.1 Navigating through the menu
Press any key to access the Main menu.
Press keys and to scroll the menu.
Press key
to select the menu option (to access another
menu or screen).
An ‘’ indicates that the menu options continue after the
last line.
Press ESC to step back to the previous level.
4.1.2 Entering the number of menu options
If you already know the number of a menu option, press
the corresponding number/s on the keypad. For example:
a. 8 Programming
b. Enter the Access Code
c. 1 Configuration
d. 1 View Configuration
e. 3 Repeater
Type in: “8 <code> 1 1 3”
SmartLoop System Running
NO Alarm
NO Fault
01/01/00 00:45 AM Sat
1 Read Log
2 Check Detectors state
3 Panel Settings
4 Disable
5 Dialler Settings
6 Printer Settings
7 Maintenance
8 Programming
