Programming Manual
The SmartLoop control panel 13
Table 3: The Bell LEDs (NAC outputs)
Table 4: The Telephone dialler LEDs
BELL Group
DESCRIPTION COLOUR MEANING
ACTIVE Red If this LED is On (solid), at least one of the 4 NAC outputs on the
control panel motherboard or on the SmartLoop/INOUT expansion
board (programmed to activate in the event alarm) or NAC alarm
output is active.
FAULT Yellow If this LED is On (solid), at least one of the 4 NAC outputs on the
control panel motherboard or on the SmartLoop/INOUT expansion
board (programmed to activate in the event alarm) or NAC alarm
output is not operating properly. If this LED blinks, a malfunction
related to the above-mentioned outputs has been cleared and saved
to the memory.
DISABLED Yellow If this LED is On (solid), at least one of the 4 NAC outputs on the
control panel motherboard or on the SmartLoop/INOUT expansion
board (programmed to activate in the event alarm) or NAC alarm
output has been disabled.
CUSTOMIZABLE 1 Yellow Can be customized by the installer.
CUSTOMIZABLE 2 Yellow Can be customized by the installer. This LED will blink during the
programming phase.
CUSTOMIZABLE 3 Yellow Can be customized by the installer.
DIALLER Group
DESCRIPTION COLOUR MEANING
ACTIVE Red If this LED is On (solid), the system is sending a communication
generated by the SmartLoop/PSTN and/or Smart/LAN board related
to an alarm or fault event. If this LED blinks, the system is sending a
communication generated by the SmartLoop/PSTN and/or Smart/
LAN board that is not related to an alarm or fault event.
FAULT Yellow If this LED is On (solid), communication with the SmartLoop/PSTN
board is not possible or a fault has been detected on one of the two
telephone lines (LE or LB). If this LED blinks, a fault related to the
SmartLoop/PSTN board or telephone lines has been cleared and
saved to the memory.
DISABLED Yellow If this LED is On (solid), alarm related telephone communications
generated by the SmartLAN board and/or fault related telephone
calls generated by the SmartLAN board cannot be sent.
