Programming Manual
16 How to view events
Chapter 5
How to view events
5.1 Overview
The system displays and deals with different real-time events in the following order of priority: Alarm,
Pre-alarm, Early Warning, Monitor, Fault, Disable, Test (refer to paragraph 12.2 The events). All
events are shown on the Control panel and Repeater displays. Events may be generated by any of the
panels in the token-ring network (refer to Chapter 24 - Programming the local network), and can
printed via the on-board thermal printer (SmartLoop2080/P and SmartLoop1010/P models only) or on
the serial printer (refer to Chapter 25 - Setting up the events printout).
If several events of the same type occur concorrently (e.g. three faults), only the first event will be
shown on the display. If the system is dealing with three fault events when a pre-alarm event occurs,
the pre-alarm will take priority).
Control panel RESET operations clear all the events from the display, however, all events will be saved
to the log and can be viewed on the control panel.
5.1.1 Active Events
FROM COMPUTER
Not available.
These are the events that occurred after the last control panel RESET operation.
FROM PANEL
This is the first of three events. Press
keys and to view other active
events.
Press ESC to view the Events menu:
Press
to select the menu option.
The option from menu 3 shows all the
events related to the selected event
type.
5.1.2 View Logger
FROM COMPUTER
Select the control panel from the system structure on the left of the screen, then select the System
Programming tab, the Events logger tab, and then click on the "Read logger saved on database" icon.
The events are recorded in chronological order. Once the log is full, any new events will overwrite old
ones (starting from the oldest). The operations at the control panel are the same as "Active Events".
Note: The contents of the log can be printed or saved to the database.
FROM PANEL
<any key>, 2 View logger,
or <any key>, 2
Event 001 of 003
PRE-ALARM WAREHOUSE
NORTH EAST SECTOR CORRIDOR
Loop n°. 4 Point 147 Control panel
1 Main Menu
2 View Log
3 View Pre-alarms
