Programming Manual
18 Initialising the configuration/programming from panel
Chapter 7
Initialising the configuration/programming from panel
The configuration/programming operations via control panel are reserved for installer company
technicians (Level 3), who can:
1. By means of a screw driver or similar tool, remove the screws and open panel box.
2. Connect the programming jumper J2 PROGRAM.
3. Access menu 8-Programming.
4. Type in a valid installer code (00004 at default).
Installer-code users can access all programming and maintenance functions.
7.1 Accessing the main menu
Once you have connected the jumper to
J2 PROGRAM select main-menu option
8 Programming.
Type in a valid installer or maintenance
technician code (Level 3).
If the jumper J2 PROGRAM is not
connected properly, the display will show
the message
Note: Access to the programming phase from a computer will not be allowed unless this jumper is
connected to the control panel.
7.2 Auto configuration of the system
This function from the control panel menu will enroll the loops, loop devices, SmartLetUSee/LCD
repeaters, SmartLoop/INOUT expansion boards and the SmartLoop/PSTN telephone dialler board.
Once a device has been configured, it will be supervised by the control panel which will signal any
change in its status (e.g. fault, etc.). Devices that are not configured cannot be supervised by the
control panel.
Note: This operation can be done from console equipped control panels only (i.e. control panels with
keypads and displays). For the other models refer to Chapter 8 - Initializing configuration/
programming from a computer.
During the AUTO Configuration phase, the control panel acknowledges all the loop devices, repeater I/
O expansion boards and the telephone dialler board and puts includes itself in the network. Once this
phase has been completed, the control panel will be able to recognize all the loop devices and will be
included in the system network.
5 Dialler Settings
6 Printer Settings
7 Maintenance
8 Programming
Enter Code
- - - - -
Internal Programming jumper
NOT inserted !!!
