Programming Manual
Initialising the configuration/programming from panel 19
You (the installer) can choose the method you use for addressing the loop devices. You can assign the
addresses manually (refer to Appendix B and Appendix C in the Installation Manual) and then enroll
them on the control panel, or command the control panel to assign the addresses automatically (this
method is for capable loop protocols only).
The auto-configuring and auto-addressing functions greatly simplify the configuration process of
difficult systems.
AUTO Configuration procedure:
1. Set the parameters of each loop.
2. Assign addresses manually to the devices of each loop (if necessary).
3. Configure the loops, repeaters, I/O expansion boards, telephone dialler and network.
4. Connect the computer and allow it to acquire the data then proceed with the programming phase.
7.2.1 Setting the loop parameters
Specify the type of loop wiring and protocol to be used (in accordance with the installed devices).
Refer to paragraph 17.1 Defining loop typology.
7.2.2 Auto-configuring loops
FROM PANEL
<any key>, 8 Programming, <code>, 1 Configuration, 2 Modify
Configuration, 1 AUTO Configuration , 2 Loop,
or
<any key>,
8
<code> 1 2 1 2
There are three ways of configuring the control panel:
Choose the method which is most suited to the particular needs of the system you are working on.
Press keys and to navigate
through the screens.
Press keys and to select (‘+’) or
deselect (‘.’) the function on each of the 8
loops.
Press key
to confirm.
The procedure may take several minutes.
A progress bar will indicate the
advancement of each phase.
On completion a report showing the
devices enrolled on each loop appears.
Press keys and to navigate
through the configured loops.
ACQUIRE DEVICES The control panel learns the manually-assigned addresses of the installed
devices, however, it will not acknowledge any devices with factory-set addresses.
Physical removal of any devices from the loop results in their automatic deletion
from the configuration.
ADDRESS NEW
DEVICES
The control panel will verify the presence of new devices (address=255) and will
assign addresses automatically, starting from the first free address available.
It will then enroll the new devices in the same way as the Acquired devices
function.
RE-ADDRESS ALL The control panel will assign address 255 to all the loop devices, re-address them
in increasing order and then enroll the new addresses.
Loop N. 1 2 3 4 5 6 7 8
ACQUIRE DEVICES : . . . . . . . .
ADDRESS NEW DEV. : . . . . . . . .
RE-ADDRESS ALL : . . . . . . . .
Loop configuration in progress ...
61% --- --- --- --- --- --- ---
Loop n°. x <Loop Description>
Detectors :xxx IN Module :xxx
OUT Module :xxx IN/OUT Mod. :xxx
Sounders :xxx Call Points :xxx
To Next Page
