Programming LED expansion boards 57
Chapter 21
Programming LED expansion boards
(Frontplate console and SmartLetUSee/LED)
Some installations require additional LEDs, on the control panel and in remote locations on the
Repeater and SmartLetUSee/LCD consoles.
In such cases you can enhance:
• each control panel with a SmartLetUSee/LED expansion board (48 additional LEDs).
• each SmartLetUSee/LCD with a SmartLetUSee/LED expansion board (48 additional LEDs).
Note: Each LED should be clearly labeled after programming.
21.1 Programming the control panel expansion board LEDs
FROM COMPUTER
Go to SmartLoop System, Control panel x, Frontplate console, SmartLetUSee/LED, System
Programming
This option will allow you to activate a LED in response to one or more signals related to a zone,
device or group.
Note: The statuses available, in the event of LED activation triggered by a specified device, vary in
accordance with the Activation Type assigned to the device concerned.
21.1.1 Procedure for each LED
1. Assign a description to the LED.
2. Select the required zone, device or group.
3. Enable the signals that will activate the LED.
FROM PANEL
Not available.
21.2 Programming SmartLetUSee/LCD expansion board LEDs
FROM COMPUTER
Go to SmartLoop System, Control panel x, RS485BUS, SmartLetUSee/LCD y, SmartLetUSee/LED,
System Programming
Follow the programming method described under "Programming the control panel expansion board
LEDs" (refer to paragraph 21.1 Programming the control panel expansion board LEDs).
FROM PANEL
Not available.
