Programming Manual
Loop device settings 53
Table 6: Signals Section activated by the device (as input)
Table 7: Signals Section that activate the device (output R)
FROM PANEL
<any key>, 8 Programming, <code>, 2 POINT Programming, x Loop,
yyy point,
or
<any key>,
8
<code> 2 x yyy
Press keys and to scroll the list or
type in the device number.
Press to confirm.
Secondary
Zones
Group of zones whose signals can be activated by the device (as input), or that can activate
the signals of the device (as output).
To the
control panel
Control panel signals activated by the device. The available signals depend on the Activation
Type you select for the device.
To the zones Signals that will be activated on ALL the control panel zones. The available signals depend on
the Activation Type you select for the device (for example, a module, that when activated
generates "Close Fire door" signals on the ENTIRE system).
To
secondary
zones
Signals that will be activated on the secondary zone group of the device. The available signals
depend on the Activation Type you select for the device (for example, a detector that goes
into alarm status and activates alarm signals on all the zones on the floor).
To the
device zone
Signals that will be activated on the zone the device belongs to (for example, a detector that
goes into alarm status and in turn activates alarm signals on the zone it belongs to).
To the
groups
Each device can activate up to three different groups. In this section, as well as selecting the
groups that will be activated, you can also select the statuses of the device that activate the
groups. The available statuses depend on the Activation Type you select for the device.
From the
Control panel
Control panel signals that activate the device output.
From the
device zone
Signals from the zone the device belongs to that activate the device output.
From the
secondary
zones
Signals of the secondary zone group associated with the device that activate its output (for
example, if you select the pre-alarm signal of the secondary outputs, and a zone that
belongs to the secondary zone group goes into pre- alarm status, the device output will
activate).
From other
zones
The output will activate, following one or more statuses of a specific device that is
programmed to follow. The available statuses depend on the Activation Type you select for
the device to follow.
From the
groups
The output will activate, if one or more groups switch to ON status. The groups that can
activate the output are the same as those selected in the Signals Section that are activated
by the device (as input).
You can program a device to activate itself when the device input activates, the output will
replicate the activation).
From special
conditions
The output activates following particular control panel statuses.
Activation
Time
If the R output is a pulse output, this is the activation time.
001 <Dev. Type> <Dev. Description>
002 <Dev. Type> <Dev. Description>
003 <Dev. Type> <Dev. Description>
004 <Dev. Type> <Dev. Description>
To Next Page
