CONNECTIONS
page11
1. CONNECT TO POWER
a. Connect the mini plug of the power cable to AC IN jack on the back of the DTV-262.
b. Connect the power plug of the power cable to the power socket.
2. SYSTEM CONNECTIONS
a. Using the antenna input: Connect the antenna terminal from an antenna or cable/satellite
receiver to the antenna input terminal on the DTV-262; use the TV/DVD/AUX/PC button and
the / buttons to set the DTV-262’s signal source to "TV".
b. Using the AV2 RCA Video/Audio input: Connect compatible AV equipment to the DTV-262
through the AV2 IN jacks on DTV-262 (Composite Video and Audio input jacks); use the
TV/DVD/AUX/PC button and the / buttons to set the DTV-262’s signal source to "AV.
c. Using the AV1 S-Video and RCA Audio input: Connect AV equipment to the DTV-262
through the AV1 IN jacks on DTV-262 (S-Video and Audio input jacks); use the
TV/DVD/AUX/PC button and the / buttons to set the DTV-262 s signal source to S-Video .
d. Using the AV3 Component input: The AV3 input may be used for Progressive scan or HDTV
inputs; use the TV/DVD/AUX/PC button and the / buttons to set the DTV-262’s signal
source to "YPbPr".
e. Using the VGA connector: Connect a PC computer to the DTV-262 through the VGA socket
on DTV-262. The Mini-plugged next to the VGA input is for audio associated with this type of
signal. Audio cables for this purpose are supplied with the DTV-262. Use the TV/DVD/AUX/PC
button and the / buttons to set the DTV-262 s signal source to VGA . DTV-262 monitor s
native resolution for computer use is 1280x768.
f. Using the DVI connector: Connect a PC computer to the DTV-262 through the DVI socket
on DTV-262. The Mini-plugged is for audio associated with this type of signal. Audio cables for
this purpose are supplied with the DTV-262. Use the TV/DVD/AUX/PC button and the /
buttons to set the DTV-262 s signal source to DVI .
g. Using the AV out, RCA Video/Audio output: Connect the DTV-262 to another TV Monitor
through the AV OUT jacks on DTV-262 (Composite Video and Audio output jacks); now you
can use the TV Monitor as an external monitor. Signals from the Antenna, AV1, AV2 and Internal
DVD player will be available at this point.
