Initialization Workflow
During printer initialization after power on, carriage will take several seconds to initialize and search for the
origin position.
Power ON
PWC Initialization
Z (Printing Platen) Axis Initialization
Error! Carriage Stops Moving
Carriage moves right-ward and
check if the origin sensor is effective
No
Continue searching for origin
sensor
15S
Carriage Stops Moving
Yes
Y (Gantry) Initialization
End
Printing Speed (600dpi)
Speed Small Dot Middle Dot Large Dot
High
1.27m/s 1.06m/s 0.84m/s
Low
1.06m/s 0.84m/s 0.63m/s
