7-9 PRINT HEAD CALIBRATION
Every time the printer is moved, printhead is replaced, parts are replaced or adjusted, or any other mechanical
operations are done, or printing parameters are changed, the printer should be aligned to achieve good and
accurate print. PCS provides options to help you do the alignment, including step calibration, step pass calibration,
vertical alignment, and horizontal alignment. Before that, the mechanical alignment of the five heads should be
done.
7-9-1 CALIBRATION WORKFLOW
Mechanical Alignment
PCS>Adjust>Step Calibration
PCS>Adjust>Vertical Calibration
PCS>Adjust>Step Pass Calibration
PCS>Adjust>Horizontal Calibration
End
