4) Screw the cap back and keep purge flushing fluid, which will come out from the nozzles.
5) Repeat step 8 and 9 to clean the print head thorougly with flushing fluid.
Not we can fill the print head with ink.
6) Switch the handle of manual 3-way valve so that ink is connected to the print head.
7) Purge ink together with air out from the ink outlets at the back of print head.
Remove the cap that is plugged on the ink tube at the ink outlet of the print head. Press Purge Ink
button to the right of carriage’s home station, ink will be purged out from the ink tube instead of
the nozzles. Stop purging until there’s no air bubbles coming out from the ink tube.
Note: Purge ink for 2-3 seconds; air in the head will be purged out completely. Do NOT purge ink
more than 5 seconds, otherwise the sub-ink-tank will be empty and air will get into the head
again.
8) Screw the cap back and keep purging ink, which will come out from the nozzles.
9) Adjust the handle position of manual three-way valve of the ink channel that has finished
supplying ink and open another ink channel.
10) Repeat steps 7 and 14 to supply ink for all the channels.
