Using the Scan Tool
VIEWING OEM ENHANCED DTCs
48 3140d
The scan tool will display a code only
if codes are present in the vehicle’s
computer memory. If no codes are
present, a “No OEM Enhanced DTC’s
are presently stored in the vehicle’s
computer” is displayed. Press the M
button to return to the Main Menu.
3. If more than one code was retrieved press the DTC/FF button, as
necessary, to display additional codes one at a time.
Whenever the Scroll function is used to view additional codes,
the scan tool’s communication link with the vehicle’s computer
disconnects. To re-establish communication, press the
POWER/LINK
button again.
4. When the last retrieved DTC has been displayed and the DTC/FF
button is pressed, the scan tool returns to the “Priority” Code.
To view additional enhanced DTCs, repeat steps 1 through 4,
above.
To exit the OEM enhanced mode, press the M button. The scan
tool returns to the Main Menu.
OEM Enhanced DTCs for Other Vehicles
When OEM Enhanced is chosen from the System Menu (and Audi,
BMW, Hyundai, Kia, Mercedes, or Volkswagen is selected when
prompted, the scan tool retrieves enhanced DTCs from the vehicle’s
computer.
1. A “One moment please message
displays while the scan tool retrieves
enhanced DTCs.
If the scan tool fails to link to the
vehicle’s computer, a “Linking
Failed” message shows on the scan
tool’s display.
- Verify the ignition is ON, then
press the POWER/LINK
button to continue.
2. To read the display:
Refer to DISPLAY FUNCTIONS on page 9 for a description of
LCD display elements.
A visible icon indicates that the
scan tool is being powered through
the vehicle’s DLC connector.
The upper right hand corner of the
display shows the number of the
code currently being displayed, the
total number of codes retrieved.
