2.5 Function Instructions of Servo Drive PG Card Terminals
Item Name Description
1 EXC
2 /EXC
Excitation Signal
3 SIN
4 SINLO
SIN Feedback Signal
5 COS
9 COSLO
COS Feedback Signal
6 PTC-P
7 PTC-N
Motor overheating protection PTC sensor,
support PTC130,PTC150 ,etc.
8 -- --
Note˖Description of Specialized signal Lines for IS300 Servo Drive (for
reference)
Signal Definition EXC- EXC+ SIN+ SIN- COS+ COS- PTC+ PTC-
Color of Encoder
Cable Line
Specialized for
IS300 Servo Drive
Red Blue Pink Grey Yellow Green White Brown
Corresponding
“MD38PG4” PG
Card Pin
1 2 3 4 5 9 6 7
