1.3 IS300 Servo Drive Brake Components Prototyping Table
Servo
drive
model
Recommended
rower of brake
resistor
Recommended
resistance
value of brake
resistor
Braking
unit
Remarks
IS300T005 300W 130ȍ
IS300T010 400W 90ȍ
IS300T015 500W 65ȍ
IS300T020
800W 43ȍ
IS300T030 1000W 32ȍ
IS300T035 1300W 25ȍ
IS300T040
1500W 22ȍ
IS300T050 2500W 16ȍ
Built-in as
standard
No special
specification
IS300T070
3.7 kW 16ȍ
Externally
connected
MDBU-35-B
IS300T080
4.5 kW
16ȍ Externally
connected
MDBU-35-B
IS300T100
5.5 kW
8ȍ Externally
connected
MDBU-70-B
IS300T140
7.5 kW
8ȍ Externally
connected
MDBU-70-B
IS300T170
4.5 kW×2
8ȍ×2 Externally
connected
MDBU-70-B×2
IS300T210
5.5 kW×2
8ȍ×2 Externally
connected
MDBU-70-B×2
IS300T250
6.5 kW×2
8ȍ×2
Externally
connected
MDBU-70-B×2
IS300T300
16kW
2.5ȍ Externally
connected
MDBU-210-B
Note: ×2 refers to two Braking units paralleled with their respective brake
resistor; the meaning of ×3 is the same with ×2.
