1.4 IS300 Servo Drive External Electrical Parts Table
Servo drive
model
Circuit
breaker
(MCCB)
A
Recommen
ded
contactor
A
Recom-
mended
input
filter A
A
Recommend-
ed conducting
Wire of main
circuit at the
input side
mm
2
Recom-
mended
conducting
wire of
main
circuit at
the output
side
mm
2
Recom-
mended
conducting
wire of
control
circuit
mm
2
IS300T005 25 16 25 4 4 1.5
IS300T010 32 25 35 4 4 1.5
IS300T015 40 32 35 4 4 1.5
IS300T020 63 40 50 4 4 1.5
IS300T030 63 40 50 6 6 1.5
IS300T035 100 63 80 6 6 1.5
IS300T040 100 63 80 10 10 1.5
IS300T050 125 100 100 16 10 1.5
IS300T070 160 100 120 16 16 1.5
IS300T080 200 125 150 25 25 1.5
IS300T100 200 125 150 35 25 1.5
IS300T140 250 160 200 50 35 1.5
IS300T170 250 160 200 70 35 1.5
IS300T210 350 350 250 120 120 1.5
IS300T250 400 400 300 150 150 1.5
IS300T300 500 400 400 185 185 1.5
