MD021 Plastic Wire Drawing Machine User Manual
value of AI
minimum input
100.0%
F1-05
AI maximum input
0.00 V to
5.00 V
5.00 V
F1-06
Corresponding
value of AI
maximum input
-100.0% to
100.0%
100.0%
F1-07
AI input filter time
0.00s to
10.00s
0.10s
The parameters listed in the preceding table specify the relationships
between the AI voltage and the value represented by the AI. When the
AI voltage exceeds the allowed maximum or minimum value, the AI
value is considered as the maximum or minimum input, as shown in
Figure 6-3.
The parameter "AI input filter time" (F1-07) specifies the time of
filtering the AI signal. The longer the filter time is, the stronger the
anti-interference capability is, which however, reduces the regulating
response; the shorter the filter time is, the weaker the anti-interference
capability is, which means a faster regulating response.
The norminal value corresponding to 100% of the AI varies according
to the application scenarios. For details, see the application
description.
Figure 6-3 Relationship between the AI voltage and corresponding
values
