www.insigniaproducts.com
18
1.5 Cu. Ft. Over-the-Range Convection Microwave
5 Secure the blower motor and blower plate to the microwave with the two screws that you previously removed.
6 Slide the exhaust adapter into the guides on the top of the blower plate and push in until it is secure in the locking tabs.
7 Remove any tape securing the damper and make sure that the damper pivots easily. You may need to adjust the
exhaust adapter to fit with your house’s exhaust duct after the microwave is installed.
You’ll need:
Blower plate screw
Blower motor screw
Exhaust adapter
Guides
Locking tab
Damper
Back of microwave
Exhaust adapter
Blower plate
Phillips screwdrivers
Exhaust adapter
