www.insigniaproducts.com
6
1.5 Cu. Ft. Over-the-Range Convection Microwave
Mounting requirements
• The space between the cabinets must be 30 in. (76.2 cm) wide. If the space between the cabinets is more than 30 in.
(76.2 cm), you’ll need filler material to fill the gap between the microwave and cabinets.
• This microwave is for installation over ranges up to 36 in. (91.4 cm) wide.
• If installing the microwave beneath smooth, flat cabinets, make sure that you leave enough space for the power cord.
• If you are going to vent your exhaust to the outside, see “
Exhaust requirements” on page 7 for exhaust duct
preparation.
66 in. (167.6 cm) or more
from the floor to the top
of the microwave
16-1/2 in.
(41.9 cm)
3
0
i
n
.
(
7
6
.
2
c
m
)
30 in.
(76.2 cm)
2 in. (5.1 cm)
Bottom edge of
the cabinet must
be 30 in. (76.2 cm)
or more from the
cooking surface.
13 in. (33 cm) max.
