www.insigniaproducts.com
12
1.5 Cu. Ft. Over-the-Range Convection Microwave
Step 3: Select a ventilation type
This microwave is designed for three types of ventilation. Select the type of ventilation you want to use, then go to the
corresponding page.
Option A - Outside top exhaust (vertical duct): See page 13
Option B - Outside back exhaust (horizontal duct): See page 22
Option C - Recirculating (non-vented/ductless): See page 32
Note: This microwave is shipped assembled for recirculation.
Note: If a wall stud is within
6 in. (15.2 cm) of the vertical
center line, you cannot use
this installation option.
Note: Requires a
charcoal filter
(included)
To Next Page
