www.insigniaproducts.com
28
1.5 Cu. Ft. Over-the-Range Convection Microwave
5 Gently remove the wires from the grooves and reroute them through the grooves on the other side of the blower
motor.
6 Roll the blower motor 90° again so that the fan blade openings are facing out the back of the microwave.
7 Cut the four webs on each knockout panel with tin snips to remove the panels.
8 Secure the blower motor and blower plate to the microwave with the two screws that you previously removed.
Caution: Edges may be sharp after removing the knockout panels. Carefully trim any sharp edges with your tin snips.
Blower plate screw
Blower motor screw
