Service Manual_2017-V1
29
15Use the vise grip pliers clamp the middle of the
process pipe, then seal welding process tube⓯⓰.
Condenser fan motor
Condenser fan motor None
Standby condenser
Standby condenser None
Piping system in the compressor case
Drain tray
1Disengage the drain tray buckle out of the compressor
bottom plate installation hole.
