6–4 Minimate Pro Operator Manual
6.2. Minimate Pro Specifications
0.00788 mm/s (0.00031 in/s)
+/- 5% or 0.5 mm/s (0.02 in/s), whichever is larger, between 4 and
125 Hz / DIN 45669-1 standard
Frequency Range (ISEE/DIN)
2 to 250 Hz, within zero to -3 dB of an ideal flat response / 1 to 315 Hz
/ 1 to 80 Hz
Standard 1.83 m (6 ft), and the DIN Geophone supports custom lengths
up to 1 km (0.6 mi).
National and Local Standards for all countries; refer to features and
benefits
Acceleration, Displacement
Calculated using entire waveform, not estimated at peak.
0.13 to 254 mm/s (0.005 to 10 in/s)
Air Overpressure Monitoring:
88 to 148 dB (500 Pa [0.072 psi] Peak)
0.0155 pa (2.2662×10-6 psi)
+/- 10% or +/- 1 dB, whichever is larger, between 4 and 125 Hz
2 to 250 Hz between -3 dB roll off points
0.00002 – 0.0715 psi in steps of 0.00001 psi (100 – 148 dB)
512, 1,024, 2,048, 4,096, 8,192, 16,384, 32,768, 65,536 S/s per
channel (independent of record time)
Event Storage – Minimate Pro4
8,000-plus 1 second Events at 1,024 S/s sample rate
Event Storage – Minimate Pro6
7,100-plus 1 second Events at 1,024 S/s sample rate with 2 geophones
Waveform Manual, Waveform, and programmed Start/Stop.
1 to 9,000 seconds (programmable in one-second steps) plus a 0.25
seconds pre-trigger
Event is recorded until activity remains below trigger level for duration
of auto window, or until available memory is filled
Recording uninterrupted by Event processing, monitoring, or
communication – no dead time
1 to 30 second intervals, and 30 seconds to 60 minutes at 30 second
intervals
800,000 intervals
Example: 11.9 days at 2 second intervals, or 355 days at 1 min.
Example: 30 days of Histogram recording at 1 minute intervals,
and over 6500 1 second waveform Events
Weight and distance stored with Event.
History printout programmable up to all Events stored
Automatic and remote downloading of data from an unattended monitor
with the Blastware Auto Call Home™ feature
Metric or Imperial, dB or Linear Air Pressure
Log GPS (Global Positioning System) data into record.
10 domed tactile with separate keys for common functions.
7-line x 32-character, high-contrast, multi-color backlit LCD
22.23 cm (8.75 in) x 11.75 cm (4.625 in) x 10.80 cm (4.25 in)
Calibration and equipment check required at 1 year to maintain
additional 1 year of warranty.
