6–10 Minimate Pro Operator Manual
Linear “L” Microphone for air pressure
measurements.
Record unattended monitoring of noise, such as
building activities, construction, traffic, and
mining operations.
ISEE Geophone Leveling
Plate
With adjustable leveling feet and integrated
bubble level. Used to mount the ISEE Geophone
to a wall or ceiling as well as ground installations.
Reduce false triggering caused by wind by installing
the fitted foam covering over the microphone
sensor.
Microphone Stand Assembly
3-part threaded alloy stand for mounting and
elevating the Linear Microphone.
The unit can trigger a local audible and/or visual
alarm through the Auxiliary I/O port.
Series IV Remote Alarm/
RS-232 Splitter Cable
Connect a Remote Alarm and Modem to the unit
simultaneously.
RS-232 Communication Cable
Connect a Series IV instrument to a 9-pin serial
port on the PC.
Use a USB Adaptor to connect to the Serial
communication cable and a USB port on the PC.
Wire Break/Make Trigger
Cable
Trigger up to six Minimate Pro units; a Wire
Break/Make Trigger Cable is required for each
unit to be triggered. The monitor‟s Auxiliary
Channel senses the wire trigger signal via a 20
gauge Make or Break wire provided by the
operator, and starts recording. Refer to the
Chapter, Optional Accessories, this manual, for
more information.
Series IV Extension Cable,
30.5 m (100 ft.)
Series IV extension cable with connectors for
ISEE and DIN Geophones, and ISEE Linear
Microphone sensors.
Series IV Extension Cable,
76.2 m (250 ft.)
Series IV extension cable with connectors for
ISEE and DIN Geophones, and ISEE Linear
Microphone sensors.
Series IV Extension Cable,
Custom Length
Must be purchased with connectors and assembly
and a specific length of extension cable (Part No.
To Next Page
