2-13
2732-006
Specifications
2732-006
Specifications
Dimensions
Figure 2-6 on page 2-14 illustrates the dimensions for the 2732-006 grips.
Table 2-12. 2732-006 Specifications
Parameter Specification
Load capacity 100 N (22 lbf)
Test application Tensile
Mechanical connection
Upper fitting
Lower fitting
Type Bm (3/16 inch Clevis pin)
Pneumatic connection
Specimen thickness - Maximum 3.2 mm (0.125 in)
Refer to Table 2-14 on page 2-15 for
compatible jaw faces
Gripping force - Maximum 1.8 kN (360 lbf)
Temperature range -70
o
to 315
o
C (-100
o
to 600
o
F)
Air pressure - Maximum 6.2 bar (90 PSI)
Weight 4 kg (8.8 lb)
Table 2-13. 2732-006 Dimensions
Letter
Designation Dimension
Measurement
mm (in)
A Width 136 (5.3)
B Effective length -Upper grip
with pullrod
with no pullrod
560 (22)
100 (3.9)
C Effective length -Lower grip 134 (5.3)
D Throat depth 47 (1.8)
E Throat depth 17 (0.7)
