2712-001 and 2712-013 M10-14179-EN
2-2
2712-001 and 2712-013
Specifications
Dimensions
Figure 2-1 on page 2-3 illustrates the grip dimensions.
Table 2-1. 2712-001 and 2712-013 Specifications
Parameter Specification
Load capacity 5 N (1 lbf)
Test application Tensile
Not suitable for through zero/reverse
stress or fatigue testing
Mechanical connection
2712-001 Upper fitting
Lower fitting
2712-013 Upper fitting
Lower fitting
Type Am
Type Dm (1/2 inch Clevis pin)
Type O (6 mm Clevis pin)
Type O (6 mm Clevis pin)
Specimen thickness - Maximum 4 mm (0.161 in)
Gripping force - Maximum 285 N (62.7 lbf)
Temperature range -29
o
to 82
o
C (-20
o
to 180
o
F)
Air pressure - Maximum 5.2 bar (75 PSI)
Weight
2712-001 (per grip)
2712-013 (per grip)
95 g (0.21 lb)
95 g (0.21 lb)
