Compatible Jaw faces
Specifications
Compatible Jaw faces
The 2712-001 and 2712-013 grips include one pair of 9.5 x 9.5 mm
(0.375 x 0.375 in) smooth jaw faces. Alternative face sizes or surfaces are not
available.
The other grip models described in this manual can be equipped with a variety of
interchangeable jaw faces in various sizes and surface types. Refer to Table 2-14
for a summary of compatible jaw faces for each model.
Table 2-14. Compatible Jaw faces
Grip Model
Jaw face
Catalog Number Surface Type
Clamping Area
(width x height)
mm (in)
2712-002
2712-019
2732-006
2702-001 Smooth ground 12 x 25 (0.5 x 1.0)
2702-002 Rubber coated 12 x 25 (0.5 x 1.0)
2702-003 Serrated 12 x 25 (0.5 x 1.0)
2702-004 Smooth ground 25 x 25 (1.0 x 1.0)
2702-005 Rubber coated 25 x 25 (1.0 x 1.0)
2702-006 Serrated 25 x 25 (1.0 x 1.0)
2702-007 Smooth ground 50 x 25 (2.0 x 1.0)
2702-008 Rubber coated 50 x 25 (2.0 x 1.0)
2702-009 Serrated 50 x 25 (2.0 x 1.0)
2702-010 Line contact 25 x 2.3 (1.0 x 0.09)
radius convex surface
2702-042 High friction compound 25 x 25 (1.0 x 1.0)
2702-043 High friction compound 50 x 25 (2.0 x 1.0)
S1-11613-1
a
Rubber coated 102 x 25 (4.0 x 1.0)
S1-11613-2
a
Smooth ground 102 x 25 (4.0 x 1.0)
