Connecting Pneumatics M10-14179-EN

3-12

Automatic Grip Control Unit

An automatic grip control integrates the grips with the load frame's control

system. Figure 3-9 illustrates the grip controller. There are various

configurations for each type. Refer to the automatic grip control unit manual for

specific installation details.

Figure 3-9. Grip Controller

Grip controller

Foot switch
