2712-002 and 2712-019 M10-14179-EN
6-8
Table 6-2. 2712-002 and 2712-019 Parts List
Item Description Part Number Quantity
2 Handle assembly & ball valve A2-44 1
5 Piston T2-247 1
6 Roller wedge T2-243 2
7 Roller link T2-245 2
8 Jaw face holder (left side) T2-248 1
9 Jaw face holder (right side) T2-249 1
10 Transfer lever T2-285 2
11 Seal backup ring 33-4-154 1
12 Seal spacer T2-275 1
13 Bearing tie rod T2-276 1
14 Valve cap T2-278 1
15 Adjustable lever guide T2-279 1
16 Valve handle T2-280 1
17 Valve seal T2-284 2
18 Stem seal T2-281 1
19 Conical spring T2-251 1
20 Piston housing (lower grip)
2712-002
2712-019
T2-282
T563-659
1
1
22 Quad ring 33-5-2 1
23 Compression spring 66-1-39 2
26 Dowel pin (1/8 x 1/4 in) 705E36 4
27 Dowel pin (1/8 x 3/8 in) 705E38 6
31 Screw (4-40 x 3/8 in) 201G2 2
32 Piston housing (upper grip)
2712-002
2712-019
T2-283
T563-659
1
1
38 Grip frame T2-286 1
To Next Page
