6-17
2712-016
Illustrated Parts
Table 6-5. 2712-016 Parts List
Item Description Part Number Quantity
1 Grip adapter
Upper grip
Lower grip
T1733-1114
T1733-1115
1
1
2 Piston housing T1733-1116 1
3 Piston T1733-1117 1
4 Roller T1733-1118 2
5 Pivot pin T1733-1119 2
6 Roller link T1733-1120 2
7 Multiplying link T1733-1121 2
8 Jaw face holder (right) T1733-1122 1
9 Jaw face holder (left) T1733-1123 1
10 Jaw frame T1733-1124 1
11 Label set (lower grip) T1733-1125 1
12 Spring T1733-1126 1
13 Bush T1733-1128 4
15 Roll pin (M5 x 30) 703E112 1
16 O-ring seal 33-2-1166 1
17 Seal ring 33-53-1098 1
18 Retainer ring, external 60-1-26 4
19 Compression spring 66-2-10 2
20 Warning hazard label (upper grip) 51-1-226 1
21 Grip identification label (upper grip) T1733-2401 1
23 Dowel pin (8 x 18 mm) 705J300 6
25 Screw (M6 x 16) 201V33 4
27 Dowel pin T1733-1133 4
28 Hole plug T1733-1129 1
30 Slot plug T1733-1130 2
