2732-003 and 2732-004 M10-14179-EN
6-20
Table 6-6. 2732-003 and 2732-004 Parts List
Item Description Part Number Quantity
1 Wedge roller T2-259 2
2 Roller link T2-261 2
3 Jaw face holder (left) T2-262 1
4 Jaw face holder (right) T2-263 1
5 Metal bellows piston seal T2-392 1
6 Piston spring T2-453 1
7 Multiplying link T2-1038 2
8 Piston stem guide T2-455 1
9 Piston housing T2-456 1
10 Hole cap T2-749 1
11 Grip frame
2732-003
2732-004
T2-458
T2-521
1
1
13 Grip nut T2-475 1
14 Bellows seal T2-518 1
15 Pull rod ring T2-539 1
16 Compression spring 66-2-10 2
17 Dowel pin (3/16 x 7/16 in) 705E69 4
18 Dowel pin (3/16 x 5/8 in) 705E72 8
19 Dowel pin (3/16 x 3/4 in) 705E74 2
21 Grip identification label
2732-003
2732-004
T2-1134
T2-1135
1
1
22 Pull rod pin T2-571 2
25 Screw, 4-40 x 1/4 in, SS 304C43 2
26 Cap screw, 10-32 x 1/2 in 201F42 4
27 Screw, 2-56 x 1/8 in, SS 304C1 4
Jaw faces Refer to Chapter 2
