2732-006 M10-14179-EN
6-22
Table 6-7. 2732-006 Parts List
Item Description Part Number Quantity
1 Assembly hose (upper grip) A2-99 1
2 Upper pullrod
Lower pullrod
A2-1021
A2-1023
1
1
3 Spring bellows return T2-519 1
4 Grip frame T2-520 1
5 Pull rod ring (lower grip) T2-539 1
6 Pull rod pin (lower grip) T2-571 2
7 Jaw face holder (left) T2-582 1
8 Jaw face holder (right) T2-583 1
9 Roller link T2-584 2
10 Transfer link T2-585 2
11 Wedge roller T2-243 2
12 Link return spring T2-593 2
13 O-ring (upper grip) 33-2-33 2
14 Allen nuts 52-2-69 4
15 Dowel pin (1/8 x 1/4 in) 705E36 4
16 Dowel pin (1/8 x3/8 in) 705E38 4
17 Link pin, 1/8 T2-1148 2
18 Screw, 2-56 x 1/8 in 304C1 14
21 Grip nut (lower grip) T2-475 1
22 Grip identification label T2-1137 1
23 Retaining ring, E-style 60-1-243 4
24 Link shield T2-577 2
25 Hole cap T2-578 1
Jaw faces Refer to Chapter 2
To Next Page
