2732-008 and 2732-009 M10-14179-EN
6-24
Table 6-8. 2732-008 and 2732-009 Parts List
Item Description Part Number Quantity
1 Wedge roller assembly A2-1048 2
2 Roller link T2-261 2
3 Jaw face holder (left) T2-262 1
4 Jaw face holder (right) T2-263 1
5 Metal bellows piston seal T2-392 1
6 Piston spring T2-453 1
7 Multiplying link T2-1145 2
8 Piston stem guide T2-455 1
9 Piston housing T2-1146 1
10 Hole cap T2-749 1
11 Grip frame
2732-008
2732-009
T2-1141
T2-1142
1
1
12 Cover grip side T2-1144 2
13 Grip nut T2-475 1
14 Bellows seal T2-518 1
15 Pullrod ring T2-539 1
16 Compression spring 66-2-10 2
17 Dowel pin (3/16 x 7/16 in) 705E69 4
18 Dowel pin (3/16 x 5/8 in) 705E72 8
19 Screw shoulder hex socket SS 9-6-19 2
21 Grip identification label
2732-008
2732-009
T2-1160
T2-1161
1
1
22 Pullrod pin T2-571 2
25 Screw 4-40 x 1/4 in, SS 304C43 2
26 Cap screw 10-32 x 1/4 in, SS 201F42 10
27 Screw 2-56 x 1/8 in, SS 304C1 4
