11
Getting to Know the AV Receiver
—Continued
M
DIGITAL OPTICAL IN 1, 2, and OUT
These optical digital audio inputs are for connecting
components with an optical digital audio output,
such as a CD player or DVD player. They’re assign-
able, which means you can assign each one to an
input selector to suit your setup. See “Digital Input
Setup” on page 40.
The optical digital audio output is for connecting a
digital recorder with an optical digital input, such as
a CD recorder.
N
REMOTE CONTROL
This (Remote Interactive) jack can be con-
nected to the jack on another -capable Inte-
gra/Onkyo component for remote and system
control.
To use , you must make an analog audio connec-
tion (RCA) between the AV receiver and the other
component, even if they are connected digitally.
O
CD IN
This analog audio input is for connecting a CD
player’s analog audio output.
P
TAPE IN/OUT
These analog audio input and output jacks are for
connecting a recorder with an analog audio input
and output, such as a cassette deck, MD recorder,
etc.
Q
GAME/TV IN
A game console or TV output can be connected
here. There’s S-Video and composite video input
jacks for connecting the video signal.
R
CBL/SAT IN
A cable or satellite receiver can be connected here.
There are S-Video and composite video input jacks
for connecting the video signal, and there are analog
audio input jacks for connecting the audio signal.
S
VCR/DVR IN/OUT
A video component, such as a VCR or DVR, can be
connected here for recording and playback. There
are S-Video and composite video input and output
jacks for connecting the video signal, and there are
analog audio input jacks for connecting the audio
signal.
T
DVD IN
This input is for connecting a DVD player. There
are S-Video and composite video input jacks for
connecting the video signal.
U
DVD FRONT L/R, CENTER, SUBWOOFER,
and SURR L/R
This analog multichannel input is for connecting a
component with a 5.1-channel analog audio output,
such as a DVD player, DVD-Audio or SACD-capa-
ble player, or an MPEG decoder.
V
SUBWOOFER PRE OUT
This analog audio output can be connected to a
powered subwoofer.
W
FRONT L/R, CENTER, and SURR L/R
SPEAKERS
These terminal posts are for connecting the front
speakers, center, and surround speakers.
X
AC INLET
The supplied power cord is connected here. The
other end of the power cord should be connected to
a suitable wall outlet.
See pages 14–33 for hookup information.
