Integra DTR-4.9 - Connecting Cassette, CDR, MiniDisc, or DAT Recorders

31
Connecting Your Components —Continued
•With connection , you can play and record or listen in Zone 2.
•To connect the recorder digitally for playback, use connections and , or and .
•To connect the recorder digitally for recording, use connection .
Connecting a Cassette, CDR, MiniDisc, or DAT Recorder
Connection AV receiver Signal flow Cassette, CDR, MD, or DAT recorder
TAPE IN L/R
TAPE OUT L/R
⇐
⇒
Analog audio L/R output
Analog audio L/R input
DIGITAL IN COAXIAL 2
⇐
Digital coaxial output
DIGITAL IN OPTICAL 2
⇐
Digital optical output
DIGITAL OPTICAL OUT
⇒
Digital optical input
ANTENNA
FM
AM
75
PRE OUT
SUB
WOOFER
COAXIAL
2
(CBL/SAT)
COAXIAL
OUT
AUDIO
IN
LR
OPTICAL
OUT
OPTICAL
2
(CD)
L
R
IN
TAPE
AUDIO
OUT
LR
L
R
TAPE
DIGITAL
OUT
b
c
a
a
OPTICAL
IN
d
Step 1:
Choose a connection that matches your recorder ( , , , or ), and then make the connection.
a b c d
Cassette, CDR, MD, etc.
Connect one or the other
These connections must be
assigned (see page 40)
a
a
b
a c
d
a
b
c
d
