Integra DTR-4.9 User Manual

83
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
Rated Output Power
90 watts minimum continuous power per channel, 8 ohm
loads, 2 channels driven from 20Hz to 20kHz, with a
maximum total harmonic distortion of 0.08% (FTC)
105 watts minimum continuous power per channel, 8 ohm
loads, 2 channels driven from 20Hz to 20kHz, with a
maximum total harmonic distortion of 0.7% (FTC)
110 watts minimum continuous power per channel, 6 ohm
loads, 2 channels driven at 1kHz, with a maximum total
harmonic distortion of 0.1% (FTC)
Dynamic Power 210 W (3 Ω , Front)
180 W (4
Ω , Front)
110 W (8
Ω , Front)
THD (Total Harmonic
Distortion) 0.08% (Power Rated)
Damping Factor 60 (Front, 1kHz, 8
Ω )
Input Sensitivity and
Impedance 200 mV/ 47 k
Ω (LINE)
Output Level and
Impedance 200 mV/ 2.2 k
Ω (REC OUT)
Frequency Response 5Hz–100kHz/ +1 dB–3 dB
Tone Control ±10 dB, 50Hz (BASS)
±10 dB, 20kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
Speaker Impedance
North American 6
Ω –16 Ω
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75
Ω (Component and S-Video Y)
0.7 Vp-p /75
Ω (Component Pb/Cb, Pr/Cr)
0.28 Vp-p /75
Ω (S-Video C)
1 Vp-p /75
Ω (Composite)
Component Video
Frequency Response 5Hz – 50MHz, –3 dB
Tuning Frequency Range 87.50MHz–107.90MHz
Tuning Frequency Range 530kHz–1710kHz
Preset Channel 40
Power Supply AC 120 V, 60Hz
Power Consumption 4.9 A
Dimensions
(W
× H × D) 435 × 173 × 391 mm
17-1/8" × 6-13/16" × 15-3/8"
Weight 11.4 kg
25.1 lbs.
HDMI (Assignable) IN 1, IN 2, IN 3
Component IN 1, IN 2
Composite DVD, VCR/DVR, CBL/SAT, GAME/TV
S-Video DVD, VCR/DVR, CBL/SAT, GAME/TV
HDMI OUT
Component OUT
Composite MONITOR OUT,
VCR/DVR OUT (REC OUT)
S-Video MONITOR OUT,
VCR/DVR OUT (REC OUT)
Digital Inputs
(Assignable) 2 (Rear OPT), 2 (Rear coax)
Analog Inputs DVD (MULTICHANNEL), VCR/DVR,
CBL/SAT, GAME//TV, TAPE, CD
Multichannel Inputs 5.1 ch
Analog Outputs TAPE, VCR/DVR, ZONE 2
Multichannel Pre
Outputs 5ch
Subwoofer Pre Outputs 1
Speaker Outputs Main (L, R, C, SL, SR)
Phones Phones
RS232 1
Ether 1
IR Input/Output 2/1
12V Trigger Out 3
DTR-4.9En.book Page 83 Tuesday, April 15, 2008 5:13 PM
