Front & Rear Panels—Continued
(6 AC INLET
This connector is for connecting the supplied power
cord.
(7 REMOTE CONTROL
This (Remote Interactive) jack can be con-
nected to an jack on another -capable Inte-
gra component. The AV receiver’s remote controller
can then be used to control that component. To use
, you must make an analog audio connection
(RCA) between the AV receiver and the other AV
component, even if they are connected digitally.
(8 COMPONENT VIDEO IN 1, 2, 3
These component video inputs can be used to con-
nect AV components with component video outputs,
such as DVD players.
(9 CD IN
This analog audio input is for connecting a CD
player’s analog audio output.
(: TAPE IN/OUT
This analog audio input and output are for connect-
ing a recorder with an analog audio input and output
(cassette, Mini Disc, etc.).
)1 GAME/TV IN
Here you can connect a game console, TV, etc.
Input jacks include S-Video, composite video, and
analog audio.
)2 COMPONENT VIDEO OUT
This component video output can be used to con-
nect a TV or projector with a component video
input.
)3 CBL/SAT IN
Here you can connect a cable/satellite receiver, set-
top box, etc. Input jacks include S-Video, composite
video, and analog audio.
)4 VCR/DVR IN/OUT
Here you can connect a VCR or DVR (digital video
recorder). Input and output jacks include S-Video,
composite video, and analog audio.
)5 DVD IN
Here you can connect a DVD player. Input jacks
include S-Video, composite video, and analog
audio. You can connect a DVD player’s 2-channel
analog audio output or 7.1-channel analog audio
output.
)6 FRONT, CENTER, SURR, and SURR BACK
SPEAKERS
These terminal posts are for connecting the front
L/R, center, surround L/R, and surround back L/R
speakers.
See pages 18-39 for connection information.
