Integra DTR-5.8 - Connecting Other AV Devices; Camcorder and Other Device Connection

33
Connecting the AV receiver—Continued
Connecting a Camcorder or Other Device
Connection AV receiver Signal flow Camcorder or console
AUX Input S Video

S-Video output
AUX Input Video

Composite video output
AUX Input Audio L/R

Analog audio L/R output
AUX Input Digital

Digital optical output
Step 1: Video Connection
Choose a video connection that matches the camcorder ( or ), and then make the connection.
A B
Step 2: Audio Connection
Choose an audio connection that matches the camcorder ( or ), and then make the connection.
a b
b
A
a
B
Digital S Video
AUX Input AUX Input
OPTICAL
OUT
AUX Input
Video
L – Audio – R
AUX Input
S VIDEO
OUT
AUDIO
OUT
VIDEO
OUT
LR
Camcorder, etc.
A
B
a
b
