Intel 8XC251SA User Manual

A-3
INSTRUCTION SET REFERENCE
Table A-2. Notation for Direct Addresses
Direct
Address.
Description
MCS
®
251
Arch.
MCS 51
Arch.
dir8 An 8-bit direct address. This can be a memory address
(00:0000H–00:00FFH) or an SFR address (S:00H - S:FFH).
✔✔
dir16 A 16-bit memory address (00:0000H–00:FFFFH) used in direct
addressing.
✔
Table A-3. Notation for Immediate Addressing
Immediate
Data
Description
MCS
®
251
Arch.
MCS 51
Arch.
#data An 8-bit constant that is immediately addressed in an instruction. ✔✔
#data16 A 16-bit constant that is immediately addressed in an instruction. ✔
#0data16
#1data16
A 32-bit constant that is immediately addressed in an instruction. The
upper word is filled with zeros (#0data16) or ones (#1data16).
✔
#short
v v
A constant, equal to 1, 2, or 4, that is immediately addressed in an
instruction.
Binary representation of #short.
✔
Table A-4. Notation for Bit Addressing
Bit
Address
Description
MCS
®
251
Arch.
MCS 51
Arch.
bit
y y y
A directly addressed bit in memory locations 00:0020H–00:007FH or in
any defined SFR.
A binary representation of the bit number (0–7) within a byte.
✔
bit51 A directly addressed bit (bit number = 00H–FFH) in memory or an SFR.
Bits 00H–7FH are the 128 bits in byte locations 20H–2FH in the on-chip
RAM. Bits 80H–FFH are the 128 bits in the 16 SFR’s with addresses
that end in 0H or 8H: S:80H, S:88H, S:90H, . . . , S:F0H, S:F8H.
✔
Table A-5. Notation for Destinations in Control Instructions
Destination
Address
Description
MCS
®
251
Arch.
MCS 51
Arch.
rel A signed (two's complement) 8-bit relative address. The destination is
-128 to +127 bytes relative to first byte of the next instruction.
✔✔
addr11 An 11-bit destination address. The destination is in the same 2-Kbyte
block of memory as the first byte of the next instruction.
✔✔
addr16 A 16-bit destination address. A destination can be anywhere within
the same 64-Kbyte region as the first byte of the next instruction.
✔✔
addr24 A 24-bit destination address. A destination can be anywhere within
the 16-Mbyte address space.
✔
