Intel 8XC251SA User Manual

A-29
INSTRUCTION SET REFERENCE
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(Rmd) ← (Rmd) + (Rms)
ADD WRjd,WRjs
Binary Mode Source Mode
Bytes: 32
States: 32
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(WRjd) ← (WRjd) + (WRjs)
ADD DRkd,DRks
Binary Mode Source Mode
Bytes: 32
States: 54
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(DRkd) ← (DRkd) + (DRks)
ADD Rm,#data
Binary Mode Source Mode
Bytes: 43
States: 32
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(Rm) ← (Rm) + #data
[Encoding] 0 0 1 0 1 1 0 0 s s s s S S S S
[Encoding] 0 0 1 0 1 1 0 1 t t t t T T T T
[Encoding] 0 0 1 0 1 1 1 1 u u u u U U U U
[Encoding] 0 0 1 0 1 1 1 0 s s s s 0 0 0 0 #data
