ADD WRj,#data16
Binary Mode Source Mode
Bytes: 54
States: 43
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(WRj) ← (WRj) + #data16
ADD DRk,#0data16
Binary Mode Source Mode
Bytes: 54
States: 65
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(DRk) ← (DRk) + #data16
ADD Rm,dir8
Binary Mode Source Mode
Bytes: 43
States: 3† 2†
†If this instruction addresses a port (P
x , x = 0–3), add 1 state.
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(Rm) ← (Rm) + (dir8)
ADD WRj,dir8
Binary Mode Source Mode
Bytes: 43
States: 43
0 0 1 0 1 1 1 0 t t t t 0 1 0 0 #data hi #data low
0 0 1 0 1 1 1 0 u u u u 1 0 0 0 #data hi #data low
[Encoding] 0 0 1 0 1 1 1 0 s s s s 0 0 0 1 direct addr
[Encoding] 0 0 1 0 1 1 1 0 t t t t 0 1 0 1 direct addr
